Model Number: SV16-LVR
In Stock

This product is available for quick shipment nationwide.

SV16-LVRSingle Lever Handle Temp/Pressure Balancing Shower Valve

The model SV16-LVR ASSE 1016 (Rev. 2011) Certified Temperature/Pressure (T/P) compensating Shower Valve meets the requirements of any shower or tub/shower application where uncompromised bather safety and comfort are required.

Key Benefits

  • Temperature/Pressure balancing shower valve
  • Ligature resistance adds another layer of bather safety

Although designed and built for the challenges of commercial and industrial facilities, it is cost-competitive with high-end Pressure Balancing Valves. The SV16 combination T/P Valve allows even the most cost-sensitive properties to meet the budget without the scalding risk associated with type P Valves.

The trim of this valve features single lever handle trim, eliminating the possibility of a pinch of the bather's fingers while closing the valve.

SV16-LVR Shower Valve Features

  • IAPMO certified at 1.25 GPM (4.7 LPM) control accuracy requirements of ASSE 1016 T/P
  • Ceramic shut-off components for long-term, drip-free reliability
  • Lead-Free certified DZR brass body with corrosion-resistant and lead-free internal components
  • A self-contained, field reversible cartridge eliminates cross-piping and offsetting of valves in back-to-back type installation
  • Commercial quality paraffin sensor provides repeatable, reliable performance
  • Integral check stops to isolate individual valves for servicing and to prevent backflow
  • A non-rising stem ensures the benefits of the trims even when the valve is fully open.
  • With the Lever Handle Trim, it eliminates a possible pinching of the bather's fingers while closing the valve
  • Single Lever trim is all-metal.
  • Serviceable inlet screens

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov - Learn More about this warning
Shows specifications for standard configuration. Configuration options may change specifications.
  • Brand
    Acorn ConTrols®
  • Material
    Brass Casting, Chrome Plated Metal Trim, Corrosion Resistant Internal Components
  • Product Features
    Single Lever Handle
  • Compliance
    No Lead - Federal Public Law 111-380, ASSE 1016, UPC, CSA B125.16
  • Flow Rate
    4 GPM (15 LPM), 150 GPM @ 45 PSI
  • Connections
    1/2" NPT Male/1/2" Sweat Inlet, 1/2" NPT Female Riser
  • Temperature Rating
    85F° - 115°F (29°C - 46°C)
  • Max Operating Pressure
    125 PSI (862 kPa)
  • Patent
    (D) Acorn Engineering Co., US 10,474,170 B2
